Features
Features
Diagnose electrical faults and CAN bus line activity
Detects data and protocol communication
Displays system voltage – Display and high/low alarm
LEDs at pinout verify signal and ECU activity
Connects between data link connector (DLC) and scan tool
Monitors system voltage – display and high/low alarm
Continuous numeric display or voltage
Check and monitor battery voltage
Connect leads for increased diagnosis, and monitoring
Probe lines with scope or DMM for detailed signal information
Ideal for troubleshooting OBD II communication issues
UNLIKE OTHER DEVICES, THIS UNIT HAS THE FOLLOWING: Digital voltage readout allows technician to view pin 16V without connecting DMM; Terminal LEDs and flashing LEDs for ECU activity allow technicians to view which pins have power, ground, and communication without connecting DMM; Color coded terminals to easily identify which pins should have power, ground, and signal; Audible signal for high/low voltage alarm – useful for wiggle tests, etc.
